Technical Details
| Approvals | CE, PSE, UL |
| Connector Type | Plug |
| Cord Length | 1.4986m |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 34.036mm |
| Introduction Date | 2021-09-29 |
| Length | 88.5mm |
| Lifecycle Status | Production |
| Max Input Voltage | 264V |
| Max Operating Temperature | 40°C |
| Max Output Current | 2.2A |
| Max Output Power | 19.8W |
| Max Output Voltage | 9.45V |
| Max Power Dissipation | 18W |
| Min Input Voltage | 90V |
| Min Operating Temperature | 0°C |
| Min Output Voltage | 8.55V |
| Nominal Input Voltage | 100V |
| Nominal Output Voltage | 9V |
| Number of Circuits | 1 |
| Number of Outputs | 1 |
| Output Voltage | 9V |
| Polarity | Positive |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Weight | 144.695966g |
| Width | 50mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
