Technical Details
| Approvals | EN, IEC, UL |
| Efficiency | 82% |
| Height | 40.64mm |
| Height - Seated (Max) | 81.28mm |
| Isolation Voltage | 4000Vrms |
| Lead Free | Lead Free |
| Length | 165.1mm |
| Lifecycle Status | Production |
| Max Input Voltage | 264V |
| Max Operating Temperature | 70°C |
| Max Output Current | 20A |
| Max Output Power | 300W |
| Max Output Voltage | 15.75V |
| Max Power Dissipation | 300W |
| Max Switching Frequency | 75kHz |
| Min Input Voltage | 90V |
| Min Operating Temperature | 0°C |
| Min Output Voltage | 14.25V |
| Mount | Chassis Mount |
| Nominal Input Voltage | 115V |
| Nominal Output Voltage | 15V |
| Number of Circuits | 1 |
| Number of Outputs | 1 |
| Number of Terminals | 12 |
| REACH SVHC | No |
| RoHS | Compliant |
| Temperature Grade | Commercial |
| Voltage - Output 1 | 15V |
| Width | 40.64mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
