Technical Details
| Approvals | EN, IEC, UL |
| Efficiency | 80% |
| Height | 40.64mm |
| Height - Seated (Max) | 81.28mm |
| Isolation Voltage | 4000Vrms |
| Lead Free | Lead Free |
| Length | 165.1mm |
| Lifecycle Status | Obsolete |
| Max Input Voltage | 264V |
| Max Operating Temperature | 70°C |
| Max Output Current | 24A |
| Max Output Power | 240W |
| Max Output Voltage | 5.25V |
| Max Power Dissipation | 120W |
| Max Switching Frequency | 55kHz |
| Min Input Voltage | 90V |
| Min Operating Temperature | 0°C |
| Min Output Voltage | 4.75V |
| Mount | Chassis Mount |
| Nominal Input Voltage | 115V |
| Nominal Output Voltage | 5V |
| Number of Circuits | 1 |
| Number of Outputs | 2 |
| Number of Terminals | 13 |
| REACH SVHC | No |
| RoHS | Compliant |
| Temperature Grade | Commercial |
| Voltage - Output 1 | 5V |
| Voltage - Output 2 | 12V |
| Width | 40.64mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
