Technical Details
| Approvals | CSA, EN, IEC |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Efficiency | 90% |
| Height - Seated (Max) | 33.8mm |
| Introduction Date | 2023-02-20 |
| Length | 91.4mm |
| Lifecycle Status | Production |
| Max Input Voltage | 264V |
| Max Operating Temperature | 85°C |
| Max Output Current | 940mA |
| Max Output Power | 45W |
| Max Output Voltage | 52.8V |
| Min Input Voltage | 80V |
| Min Operating Temperature | -40°C |
| Min Output Voltage | 43.2V |
| Nominal Input Voltage | 115V |
| Nominal Output Voltage | 48V |
| Number of Circuits | 1 |
| Number of Outputs | 1 |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Width | 60.5mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
