Technical Details
| Approvals | CE, UL |
| Case/Package | DIP |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Efficiency | 90% |
| Features | OCP, OTP, OVP, SCP, UVLO |
| Height | 12.7mm |
| Introduction Date | 2013-03-18 |
| Isolation Voltage | 1500Vrms |
| Lead Free | Lead Free |
| Length | 57.9mm |
| Lifecycle Status | Production |
| Max Input Voltage | 75V |
| Max Operating Temperature | 105°C |
| Max Output Current | 10A |
| Max Output Power | 33W |
| Max Output Voltage | 3.63V |
| Max Power Dissipation | 33W |
| Min Input Voltage | 18V |
| Min Operating Temperature | -40°C |
| Min Output Voltage | 2.97V |
| Mount | Through Hole |
| Nominal Input Voltage | 48V |
| Nominal Output Voltage | 3.3V |
| Number of Circuits | 1 |
| Number of Outputs | 1 |
| Number of Terminals | 8 |
| Output Power | 33W |
| Packaging | Bulk |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Voltage - Output 1 | 3.3V |
| Weight | 63.000011g |
| Width | 36.8mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
