Technical Details
| Case/Package | 1206 |
| Case Code (Imperial) | 1206 |
| Case Code (Metric) | 3216 |
| Color | Yellow |
| Country of Origin | Malaysia |
| Dominant Wavelength | 587nm |
| Forward Current | 30mA |
| Forward Voltage | 2.4V |
| Height | 800µm |
| Harmonized Tariff Schedule (HTS) Code | 8541.40.20.00 |
| Illumination Color | Yellow |
| Introduction Date | 2008-03-25 |
| Lead Free | Lead Free |
| Length | 3.2mm |
| Lens Style | Clear, Colorless, Diffused, Round |
| Lifecycle Status | Production |
| Luminous Intensity | 28mcd |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Circuits | 1 |
| Number of LEDs | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Peak Wavelength | 588nm |
| Power Dissipation | 76mW |
| Power Rating | 75mW |
| REACH SVHC | Yes |
| Reverse Voltage | 5V |
| RoHS | Compliant |
| Schedule B | 8541402000, 8541402000|8541402000|8541402000|8541402000|8541402000 |
| Shape | Round |
| Terminal Pitch | 2.6mm |
| Test Current | 20mA |
| Viewing Angle | 70° |
| Wavelength | 587nm |
| Width | 1.6mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
