Country of Origin	Mainland China
Export Control Classification Number (ECCN) Code	EAR99
Element Configuration	Single
Forward Voltage	1V
Harmonized Tariff Schedule (HTS) Code	85411000
Introduction Date	1993-06-30
Lifecycle Status	Production
Manufacturer Lifecycle Status	ACTIVE
Max Forward Surge Current (Ifsm)	100A
Max Operating Temperature	175°C
Max Output Current	3A
Min Operating Temperature	-50°C
Mount	Axial
Number of Elements	1
Number of Pins	2
Number of Terminals	2
Peak Non-Repetitive Surge Current	200A
Polarity	Standard
REACH SVHC	Unknown
Reverse Standoff Voltage	1kV
RoHS	Compliant
Schedule B	8541100080, 8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080, 8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080, 8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080\|8541100080
Weight	988mg

Manufacturer	Manufacturer Part No.	Lifecycle Status Indicator
HY Electronic	1N5408	Unknown
Vishay	1N5408/1	Obsolete
Vishay	1N5408-E3	Production
Diodes Inc.	1N5408	Production
Rectron	1N5408	Production
Lite-On	1N5408	Obsolete
Vishay	1N5408-E3/73	Production
Vishay	1N5408-E3/54	Production
onsemi	1N5408RL	Obsolete
Rectron	1N5408-T	Production

1N5408 - Diotec

Rectifier Diode, 1 Phase, 1 Element, 3A, 1000V V(RRM), Silicon, DO-201
