NDS-02V - Diptronics
2 positions SPST Red Flat Toggle, Raised Style Plugin DIP Switches ROHS
Technical Details
| Actuator Length | 1.1938mm |
| China RoHS | Compliant |
| Color | Red |
| Contact Plating | Gold |
| Contact Resistance | 50mΩ |
| Country of Origin | Mainland China |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 2kcycles |
| Height | 5.85mm |
| Harmonized Tariff Schedule (HTS) Code | 8536.50.90.65 |
| Insulation Resistance | 100MΩ |
| Introduction Date | 2012-11-28 |
| Length | 9.9mm |
| Lifecycle Status | Production |
| Max Current Rating | 25mA |
| Max Operating Temperature | 85°C |
| Max Voltage Rating (DC) | 24V |
| Min Operating Temperature | -40°C |
| Number of Circuits | 2 |
| Number of Pins | 2 |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Throw Configuration | SPST |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
