320E11BLU - E-Switch
Switch Tactile N.O. SPST Square Button PC Pins 0.025A 50VDC 1.32N Thru-Hole
Technical Details
| Actuator Length | 2.55mm |
| Actuator Material | PC, Polycarbonate |
| Contact Current Rating | 25mA |
| Contact Material | Copper |
| Contact Plating | Silver |
| Contact Resistance | 50mΩ |
| Current Rating | 25mA |
| Electrical Life | 1Mcycles |
| Housing Material | Nylon |
| Illumination Type | Non-Illuminated |
| Lead Free | Lead Free |
| Length | 12.5mm |
| Max Operating Temperature | 70°C |
| Max Voltage Rating (DC) | 50V |
| Mechanical Life | 1Mcycles |
| Min Operating Temperature | -20°C |
| Mount | Through Hole |
| Number of Positions | 2 |
| Packaging | Bulk |
| RoHS | Compliant |
| Switch Function | Off-Mom |
| Switch Travel | 600µm |
| Termination | PC Pin |
| Throw Configuration | SPST |
| Voltage Rating (DC) | 50V |
| Width | 12.5mm |
Compliance
RoHS : Unconfirmed
Images
Onlinecomponents.com
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| E-Switch | Production | ||
| E-Switch | Production | ||
| Grayhill | Production | ||
| E-Switch | Obsolete | ||
| E-Switch | Production | ||
| E-Switch | Production | ||
| E-Switch | Production | ||
| E-Switch | Obsolete | ||
| Grayhill | Production | ||
| Grayhill | Production |
