LP4OA1PBCTG - E-Switch
Pushbutton Switch, DPDT, Momentary, 0.1A, 30VDC, Solder Terminal, Through Hole-straight
Technical Details
| Current Rating | 100mA |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 3.5mm |
| Hole Diameter | 8.2mm |
| Harmonized Tariff Schedule (HTS) Code | 8536.50.90.31 |
| Illumination Color | Green |
| Illumination Type | Illuminated, LED |
| Introduction Date | 2013-01-30 |
| Lead Free | Lead Free |
| Length | 10mm |
| Lifecycle Status | Production |
| Max Current Rating | 100mA |
| Max Operating Temperature | 70°C |
| Max Voltage Rating (DC) | 30V |
| Mechanical Life | 50kcycles |
| Min Operating Temperature | -20°C |
| Mount | Through Hole |
| Number of Positions | 2 |
| Operating Force | 3.43N |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Switch Function | On-Mom |
| Termination | PC Pin |
| Throw Configuration | DPDT |
| Voltage Rating (DC) | 30V |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
