09.03201.02 - EAO Switch
Switch Slide ON ON SPDT Raised Slide 0.5A 24VAC 24VDC 6VA 10000Cycle PC Pins Thru-Hole
Technical Details
| Actuator Length | 1.397mm |
| Actuator Material | Plastic |
| Color | Red |
| Contact Current Rating | 500mA |
| Contact Material | Gold |
| Contact Plating | Gold |
| Contact Resistance | 22mΩ |
| Contact Voltage Rating (AC) | 12V |
| Country of Origin | Switzerland |
| Depth | 2.5mm |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 1kcycles |
| Height | 4.5mm |
| Harmonized Tariff Schedule (HTS) Code | 8536.50.90.50 |
| Insulation Resistance | 10GΩ |
| Introduction Date | 2009-01-20 |
| Length | 10mm |
| Life (Cycles) | 1kcycles |
| Lifecycle Status | Production |
| Max Current Rating | 500mA |
| Max Operating Temperature | 85°C |
| Max Voltage Rating (DC) | 12V |
| Min Operating Temperature | -40°C |
| Mount | Through Hole |
| Number of Positions | 1 |
| Orientation | Vertical |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Termination | PC Pins |
| Throw Configuration | SPDT |
| Voltage Rating (DC) | 12V |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
