MC14015BCP - Freescale Semiconductor
Serial In Parallel Out, 4000/14000/40000 Series, 4-Bit, Right Direction, True Output, CMOS, PDIP16
Technical Details
| Case/Package | DIP |
| China RoHS | Non-Compliant |
| Clock Edge Trigger Type | Positive Edge |
| Height - Seated (Max) | 4.44mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.00.60 |
| Length | 19.175mm |
| Max Operating Temperature | 125°C |
| Max Supply Voltage | 18V |
| Min Operating Temperature | -55°C |
| Min Supply Voltage | 3V |
| Number of Bits | 4 |
| Number of Circuits | 2 |
| Number of Terminals | 16 |
| Operating Supply Voltage | 5V |
| Propagation Delay | 750ns |
| RoHS | Non-Compliant |
| Temperature Grade | Military |
| Terminal Pitch | 2.54mm |
| Width | 7.62mm |
Compliance
RoHS : Unconfirmed
