71A36-06-2-05N - Grayhill
Rotary Switch, 1/8" shaft, 36°, 6 deck, 2 pole/deck, 5 position/pole, non-shorting
Technical Details
| Actuator Length | 9.53mm |
| Contact Current Rating | 300mA |
| Contact Material | Silver |
| Contact Style | Non-Shorting |
| Contact Voltage Rating (AC) | 115V |
| Current Rating | 250mA |
| Electrical Life | 15kcycles |
| Height | 54.13mm |
| Index Angle | 36° |
| Index Stops | Fixed |
| Length | 17.45mm |
| Lifecycle Status | Production |
| Max Voltage Rating (AC) | 115V |
| Max Voltage Rating (DC) | 30V |
| Mount | Panel |
| Number of Circuits | 1 |
| Number of Decks | 6 |
| Number of Poles per Deck | 2 |
| Number of Positions | 5 |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Termination | Solder |
| Throw Configuration | DP5T |
| Voltage Rating (AC) | 115V |
| Voltage Rating (DC) | 30V |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
