71BDF30-02-2-AJN - Grayhill
Switch Rotary DP6T 6 Flatted Shaft PC Pins 0.3A 115VAC 30VDC Automotive
Technical Details
| Actuator Length | 9.53mm |
| Actuator Material | Stainless Steel |
| Contact Current Rating | 250mA |
| Contact Material | Silver |
| Contact Resistance | 50mΩ |
| Contact Style | Non-Shorting |
| Current Rating | 250mA |
| Height | 27.18mm |
| Index Angle | 30° |
| Index Stops | Adjustable |
| Introduction Date | 2007-05-01 |
| Lead Free | Contains Lead |
| Life (Cycles) | 25kcycles |
| Lifecycle Status | Production |
| Max Voltage Rating (AC) | 115V |
| Max Voltage Rating (DC) | 30V |
| Mount | Through Hole |
| Number of Decks | 2 |
| Number of Pins | 6 |
| Number of Poles per Deck | 2 |
| Number of Positions | 6 |
| Orientation | Right Angle |
| Packaging | Bulk |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Termination | PC Pins |
| Throw Configuration | DP6T |
| Voltage Rating (AC) | 115V |
| Voltage Rating (DC) | 30V |
| Weight | 14g |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
