71MB30-05-1-06N - Grayhill
Rotary Switch, Military, 1/4" shaft, 30°, 5 deck, 1 pole/deck, 2 position/pole, non-shorting
Technical Details
| Contact Current Rating | 75mA |
| Contact Material | Silver |
| Contact Voltage Rating (AC) | 115V |
| Country of Origin | USA |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 41.48mm |
| Harmonized Tariff Schedule (HTS) Code | 8536.50.90.20 |
| Index Angle | 30° |
| Introduction Date | 2007-05-01 |
| Length | 17.45mm |
| Lifecycle Status | Production |
| Max Current Rating | 125mA |
| Max Voltage Rating (AC) | 115V |
| Max Voltage Rating (DC) | 28V |
| Mount | Panel |
| Number of Circuits | 1 |
| Number of Positions | 6 |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Sealable | SHAFT AND PANEL SEALED |
| Termination | Solder |
| Throw Configuration | SP6T |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
