78J01T - Grayhill
Switch DIP OFF ON SPDT 1 Raised Slide 0.15A 30VDC PC Pins 2000Cycles 2.54mm Thru-Hole Tube
Technical Details
| Actuator Length | 1.27mm |
| Body Material | Thermoplastic |
| Contact Current Rating | 150mA |
| Contact Plating | Gold |
| Contact Resistance | 100mΩ |
| Country of Origin | Mainland China |
| Current Rating | 150mA |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 2kcycles |
| Height | 6.73mm |
| Harmonized Tariff Schedule (HTS) Code | 8536.50.90.65 |
| Introduction Date | 2007-04-30 |
| Lead Free | Lead Free |
| Length | 9.65mm |
| Life (Cycles) | 2kcycles |
| Lifecycle Status | Production |
| Max Current Rating | 150mA |
| Max Operating Temperature | 85°C |
| Max Voltage Rating (DC) | 30V |
| Mechanical Life | 2kcycles |
| Min Operating Temperature | -40°C |
| Mount | Through Hole |
| Number of Circuits | 1 |
| Number of Positions | 1 |
| Orientation | Straight |
| Pitch | 2.54mm |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Terminal Pitch | 2.54mm |
| Termination | PC Pins |
| Throw Configuration | SPDT |
| Voltage Rating (DC) | 30V |
| Washable | No |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
