94HAB08WT - Grayhill
Switch DIP N.O./N.C. SP8T 8 Flush Screwdriver 0.03A 30VDC Gull Wing 10000Cycles 2.54mm SMD Tube
Technical Details
| Actuator Length | 0m |
| Actuator Material | Plastic |
| Body Material | Plastic |
| Contact Plating | Gold |
| Contact Resistance | 50mΩ |
| Depth | 12.7mm |
| Electrical Life | 10kcycles |
| Height | 11.25mm |
| Lead/Base Style | Gull Wing |
| Lead Free | Lead Free |
| Length | 11mm |
| Lifecycle Status | Production |
| Material | Plastic |
| Max Current Rating | 30mA |
| Max Operating Temperature | 85°C |
| Max Voltage Rating (DC) | 30V |
| Mechanical Life | 10kcycles |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Circuits | 1 |
| Number of Positions | 8 |
| Pitch | 2.54mm |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Switching Current | 30mA |
| Switching Voltage | 30V |
| Terminal Pitch | 2.54mm |
| Termination | Gull Wing |
| Throw Configuration | SP8T |
| Voltage Rating (DC) | 50V |
| Washable | Yes |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
