Technical Details
| Actuator Diameter | 40mm |
| Actuator Length | 10.2mm |
| Color | Red |
| Contact Current Rating | 100A |
| Contact Material | Silver |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 10Mcycles |
| Harmonized Tariff Schedule (HTS) Code | 8536.50.70.00 |
| Illumination Color | Red |
| Introduction Date | 2018-04-25 |
| Lifecycle Status | Production |
| Max Operating Temperature | 50°C |
| Max Voltage Rating (AC) | 440V |
| Max Voltage Rating (DC) | 220V |
| Mechanical Life | 5Mcycles |
| Min Operating Temperature | -25°C |
| Mount | Panel |
| Orientation | Straight |
| Ratings | IP65 |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Termination | Contact Block |
| Throw Configuration | SPDT |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
