Technical Details
| Case/Package | LSSOP |
| China RoHS | Compliant |
| Country of Origin | Mainland China |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 1.45mm |
| Height - Seated (Max) | 1.27mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.00.60 |
| Introduction Date | 2017-10-09 |
| Length | 2.9mm |
| Lifecycle Status | Production |
| Max Junction Temperature (Tj) | 150°C |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 600mW |
| Max Supply Current | 2.3mA |
| Max Supply Voltage | 42V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 6V |
| Number of Channels | 1 |
| Number of Characters | 3 |
| Number of Circuits | 1 |
| Number of Outputs | 1 |
| Number of Terminals | 6 |
| Operating Supply Voltage | 24V |
| Output Current | 100mA |
| Output Voltage | 42V |
| Package Quantity | 3000 |
| Packaging | Tape & Reel |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Schedule B | 8542390000 |
| Terminal Pitch | 950µm |
| Width | 1.6mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
