Technical Details
| Body Material | Metal |
| China RoHS | Compliant |
| Contact Plating | Silver |
| Continuous Drain Current (ID) | 9A |
| Country of Origin | Austria, Mainland China, Malaysia, Mexico |
| Drain to Source Resistance | 5.6mΩ |
| Drain to Source Voltage (Vdss) | 100V |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Gate to Source Voltage (Vgs) | 20V |
| Halogen Free | Halogen Free |
| Input Capacitance | 4.1nF |
| Introduction Date | 2011-03-10 |
| Lead Free | Lead Free |
| Lifecycle Status | Production |
| Max Dual Supply Voltage | 100V |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 78W |
| Min Breakdown Voltage | 100V |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Elements | 1 |
| Number of Pins | 3 |
| Number of Terminals | 3 |
| On-State Resistance | 5.6mΩ |
| Package Quantity | 5000 |
| Packaging | Tape & Reel |
| Power Dissipation | 78W |
| Radiation Hardening | No |
| Rds On Max | 5.6mΩ |
| REACH SVHC | Yes |
| Rise Time | 9ns |
| RoHS | Compliant |
| Schedule B | 8541290080, 8541290080|8541290080|8541290080|8541290080|8541290080 |
| Threshold Voltage | 2.7V |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
Images
Farnell
Authorized Distributors
| Distributor | SKU | Stock | USD | 1 | 10 | 50 | 100 | 1000 | 10000 | Buy |
|---|---|---|---|---|---|---|---|---|---|---|
| Mouser |
US: 806
|
$ | 3.62 | 2.36 | 2.36 | 1.85 | 1.34 | 1.34 | ||
| Farnell |
DE: 0
|
$ | 3.9694 | 2.675 | 2.675 | 2.675 | 2.675 | 2.675 | ||
| Farnell |
DE: 0
|
$ | 2.675 | 2.675 | 2.675 | |||||
