CY62157ESL-45ZSXI - Infineon
CY62157ESL Series 8-Mbit (512 K x 16) 2.2 to 3.6 V 45 ns Static RAM - TSOP II-44
Technical Details
| Access Time | 45ns |
| Address Bus Width | 19b |
| Ambient Temperature Range High | 85°C |
| Case/Package | TSOP |
| China RoHS | Compliant |
| Density | 8Mb |
| Export Control Classification Number (ECCN) Code | 3A991.B.2.A |
| Height | 1.194mm |
| Height - Seated (Max) | 1.194mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.32.00.41 |
| Interface | Parallel |
| Introduction Date | 2008-01-04 |
| Lead Free | Lead Free |
| Length | 18.415mm |
| Lifecycle Status | Production |
| Max Frequency | 22MHz |
| Max Operating Temperature | 85°C |
| Max Supply Current | 25mA |
| Max Supply Voltage | 3.6V |
| Memory Size | 1MB |
| Memory Type | SRAM |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 2.2V |
| Mount | Surface Mount |
| Nominal Supply Current | 25mA |
| Number of Circuits | 1 |
| Number of Pins | 44 |
| Number of Ports | 1 |
| Number of Terminals | 44 |
| Number of Words | 512000 |
| Operating Supply Voltage | 3V |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Schedule B | 8542320040 |
| Sync/Async | Asynchronous |
| Temperature Grade | Industrial |
| Terminal Pitch | 800µm |
| Width | 10.16mm |
| Word Size | 16b |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
