CY7C1061G30-10BVJXI - Infineon
SRAM Chip Async Single 3V 16M-Bit 1M x 16 10ns 48-Pin VFBGA Tray
Technical Details
| Access Time | 10ns |
| Ambient Temperature Range High | 85°C |
| China RoHS | Compliant |
| Export Control Classification Number (ECCN) Code | 3A991.b.2.a |
| Height | 1mm |
| Height - Seated (Max) | 1mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.32.00.41 |
| Interface | Parallel |
| Introduction Date | 2014-05-09 |
| Length | 8mm |
| Lifecycle Status | Production |
| Max Operating Temperature | 85°C |
| Max Supply Voltage | 3.6V |
| Memory Size | 2MB |
| Memory Type | SRAM |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 2.2V |
| Nominal Supply Current | 90mA |
| Number of Circuits | 1 |
| Number of Pins | 48 |
| Number of Terminals | 48 |
| Operating Supply Voltage | 3V |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Temperature Grade | Industrial |
| Terminal Pitch | 750µm |
| Width | 6mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
