CY7C1373KV33-133AXI - Infineon
CY7C1373KV33 18-Mb (512 K × 36/1 M × 18) 133 MHz Flow-Through SRAM - TQFP-100
Technical Details
| Access Time | 6.5ns |
| Ambient Temperature Range High | 85°C |
| Case/Package | LQFP |
| China RoHS | Compliant |
| Export Control Classification Number (ECCN) Code | 3A991.B.2.B |
| Frequency | 133MHz |
| Height | 1.6mm |
| Height - Seated (Max) | 1.6mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.32.00.41 |
| Interface | Parallel |
| Introduction Date | 2016-01-14 |
| Length | 20mm |
| Lifecycle Status | Production |
| Max Operating Temperature | 85°C |
| Max Supply Voltage | 3.6V |
| Memory Size | 2.3MB |
| Memory Type | SRAM |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 3.135V |
| Number of Circuits | 1 |
| Number of Terminals | 100 |
| Operating Supply Voltage | 3.3V |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Temperature Grade | Industrial |
| Terminal Pitch | 650µm |
| Width | 14mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
