ESD105B102ELSE6327XTSA1 - Infineon
TVS DIODE 5.5VWM 14VC TSSLP-2-4 14V Clamp 5A (8/20µs) Ipp Tvs Diode Surface Mount PG-TSSLP-2-4
Technical Details
| Capacitance | 450fF |
| China RoHS | Compliant |
| Clamping Voltage | 14V |
| Composition | Zener |
| Depth | 320µm |
| Direction | Bidirectional |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Single |
| Halogen Free | Halogen Free |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 2014-01-09 |
| Lead Free | Lead Free |
| Leakage Current | 20nA |
| Length | 620µm |
| Lifecycle Status | Obsolete |
| Max Breakdown Voltage | 14V |
| Max Operating Temperature | 125°C |
| Max Surge Current | 5A |
| Min Breakdown Voltage | 6.1V |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Bidirectional Channels | 1 |
| Number of Elements | 1 |
| Number of Lines | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Package Quantity | 15000 |
| Packaging | Tape & Reel |
| Peak Pulse Current | 5A |
| Peak Pulse Power | 70W |
| Peak Reverse Current | 20nA |
| Polarity | Bidirectional |
| Power Line Protection | No |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Reverse Standoff Voltage | 5.5V |
| RoHS | Compliant |
| Working Voltage | 5.5V |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
