ESD5V5S1B-02LRH - Infineon
Trans Voltage Suppressor Diode, 150W, 5.5V V(RWM), Bidirectional, 1 Element, Silicon
Technical Details
| Breakdown Voltage | 8V |
| China RoHS | Compliant |
| Clamping Voltage | 9.4V |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 2012-08-17 |
| Lifecycle Status | Obsolete |
| Max Breakdown Voltage | 10V |
| Max Operating Temperature | 125°C |
| Min Breakdown Voltage | 6V |
| Min Operating Temperature | -55°C |
| Number of Elements | 1 |
| Number of Terminals | 2 |
| Peak Pulse Power | 150W |
| Peak Reverse Current | 100nA |
| Polarity | Bidirectional |
| REACH SVHC | Yes |
| Reverse Standoff Voltage | 5V |
| RoHS | Compliant |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
