ILD4001E6327HTSA1 - Infineon
ILD4001 Series 40 V 500 kHz Surface Mount Step Down LED Controller - SC-74-6
Technical Details
| Case/Package | TSOP |
| China RoHS | Compliant |
| Contact Plating | Tin |
| Dimming | Analog, PWM |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Frequency | 500kHz |
| Halogen Free | Not Halogen Free |
| Height - Seated (Max) | 1.1mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.00.60 |
| Introduction Date | 2011-06-09 |
| Lead Free | Lead Free |
| Length | 2.9mm |
| Lifecycle Status | Obsolete |
| Max Operating Temperature | 150°C |
| Max Output Current | 10mA |
| Max Power Dissipation | 1W |
| Max Supply Voltage | 42V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 4.5V |
| Mount | Surface Mount |
| Number of Characters | 3 |
| Number of Circuits | 1 |
| Number of Outputs | 1 |
| Number of Pins | 6 |
| Number of Terminals | 6 |
| Operating Supply Voltage | 12V |
| Power Dissipation | 1W |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Terminal Pitch | 950µm |
| Width | 1.6mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
Images
Farnell
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Infineon | Obsolete | ||
| Infineon | Obsolete | ||
| Infineon | Production | ||
| Infineon | Obsolete | ||
| Diodes Inc. | Obsolete | ||
| Infineon | Obsolete | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production |
Authorized Distributors
| Distributor | SKU | Stock | USD | 1 | 10 | 50 | 100 | 1000 | 10000 | Buy |
|---|---|---|---|---|---|---|---|---|---|---|
| Farnell |
GB: 0
|
$ | 0.3252 | 0.2504 | 0.2028 | |||||
