ILD6150XUMA1 - Infineon
ILD6150 Series 60 V 1.5 A High Efficiency Step-Down LED Driver IC - PG-DSO-8
Technical Details
| Case/Package | SOP |
| China RoHS | Compliant |
| Country of Origin | Malaysia |
| Dimming | Analog, PWM |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Frequency | 1MHz |
| Halogen Free | Halogen Free |
| Height - Seated (Max) | 1.7mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.00.60 |
| Introduction Date | 2013-02-07 |
| Lead Free | Lead Free |
| Length | 4.9mm |
| Lifecycle Status | Production |
| Max Input Voltage | 60V |
| Max Operating Temperature | 150°C |
| Max Output Current | 1.5A |
| Max Output Voltage | 60V |
| Max Supply Current | 2.8mA |
| Max Supply Voltage | 60V |
| Min Input Voltage | 4.5V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 4.5V |
| Mount | Surface Mount |
| Number of Channels | 1 |
| Number of Characters | 3 |
| Number of Circuits | 1 |
| Number of Outputs | 1 |
| Number of Pins | 8 |
| Number of Terminals | 8 |
| Operating Supply Voltage | 12V |
| Output Current | 1.5A |
| Output Current per Channel | 1.5A |
| Package Quantity | 2500 |
| Packaging | Tape & Reel |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Switching Frequency | 1MHz |
| Terminal Pitch | 1.27mm |
| Type | Integrated Circuit (IC) |
| Width | 3.9mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
