IPI70N10SL16AKSA1 - Infineon
MOSFET N-CH 100V 70A TO262-3 N-Channel 100 V 70A (Tc) 250W (Tc) Through Hole PG-TO262-3
Technical Details
| Case/Package | TO-262-3 |
| China RoHS | Compliant |
| Continuous Drain Current (ID) | 70A |
| Drain to Source Resistance | 25mΩ |
| Drain to Source Voltage (Vdss) | 100V |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Fall Time | 95ns |
| Gate to Source Voltage (Vgs) | 20V |
| Halogen Free | Halogen Free |
| Input Capacitance | 4.54nF |
| Introduction Date | 2006-06-14 |
| Lead Free | Contains Lead |
| Lifecycle Status | Production |
| Max Dual Supply Voltage | 100V |
| Max Operating Temperature | 175°C |
| Max Power Dissipation | 250W |
| Min Breakdown Voltage | 100V |
| Min Operating Temperature | -55°C |
| Mount | Through Hole |
| Number of Elements | 1 |
| Number of Pins | 3 |
| Number of Terminals | 3 |
| On-State Resistance | 16mΩ |
| Package Quantity | 500 |
| Power Dissipation | 250W |
| Rds On Max | 16mΩ |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Turn-Off Delay Time | 250ns |
| Turn-On Delay Time | 70ns |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
