ITS711L1FUMA1 - Infineon
IC PWR SWITCH N-CHAN 1: 1 DSO-20 Power Switch/Driver 1: 1 N-Channel 1.7A PG-DSO-20-31
Technical Details
| Case/Package | SOP |
| China RoHS | Compliant |
| Current | 4.4A |
| Drain to Source Resistance | 50mΩ |
| Drain to Source Voltage (Vdss) | 34V |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 2.45mm |
| Height - Seated (Max) | 2.65mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.00.60 |
| Introduction Date | 2006-03-30 |
| Lead Free | Lead Free |
| Length | 12.8mm |
| Lifecycle Status | Production |
| Max Operating Temperature | 85°C |
| Max Output Current | 7.5A |
| Max Power Dissipation | 3.6W |
| Max Supply Current | 8mA |
| Max Supply Voltage | 34V |
| Min Operating Temperature | -30°C |
| Min Supply Voltage | 5V |
| Nominal Supply Current | 8mA |
| Number of Channels | 4 |
| Number of Circuits | 1 |
| Number of Outputs | 4 |
| Number of Pins | 20 |
| Number of Terminals | 20 |
| Number of Transmitters | 4 |
| On-State Resistance | 200mΩ |
| Operating Supply Voltage | 12V |
| Output Current | 4.1A |
| Output Current per Channel | 2.9A |
| Package Quantity | 1000 |
| Packaging | Tape & Reel |
| Power Dissipation | 3.6W |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Resistance | 165mΩ |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Temperature Grade | Commercial Extended |
| Terminal Pitch | 1.27mm |
| Termination | SMD/SMT |
| Voltage | 34V |
| Width | 7.6mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
