IS25LP064A-JBLE - ISSI
NOR Flash Serial (SPI, Dual SPI, Quad SPI) 2.5V/3V/3.3V 64M-bit 8M x 8 8ns 8-Pin SOIC
Technical Details
| Access Time | 7ns |
| Address Bus Width | 24b |
| Case/Package | SOP |
| China RoHS | Compliant |
| Country of Origin | Mainland China, Taiwan |
| Density | 64Mb |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Frequency | 133MHz |
| Height | 2.16mm |
| Height - Seated (Max) | 2.16mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.32.00.51 |
| Interface | Serial |
| Introduction Date | 2015-04-09 |
| Length | 5.28mm |
| Lifecycle Status | Production |
| Max Frequency | 133MHz |
| Max Operating Temperature | 105°C |
| Max Supply Current | 25mA |
| Max Supply Voltage | 3.6V |
| Memory Size | 8MB |
| Memory Type | FLASH |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 2.3V |
| Number of Circuits | 1 |
| Number of Pins | 8 |
| Number of Terminals | 8 |
| Operating Supply Voltage | 3V |
| Page Size | 256B |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Schedule B | 8542320070, 8542320070|8542320070|8542320070|8542320070|8542320070 |
| Temperature Grade | Industrial |
| Terminal Pitch | 1.27mm |
| Width | 5.28mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
