IS61WV2568EDBLL-10TLI - ISSI
SRAM Chip Async Single 2.5V/3.3V 2Mbit 256K X 8 10ns 44-Pin TSOP-II Tray
Technical Details
| Access Time | 10ns |
| Address Bus Width | 18b |
| Case/Package | TSOP |
| China RoHS | Compliant |
| Country of Origin | Mainland China, Taiwan |
| Density | 2Mb |
| Export Control Classification Number (ECCN) Code | 3A991.b.2.a |
| Height - Seated (Max) | 1.2mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.32.00.41 |
| Interface | Parallel |
| Introduction Date | 2011-12-09 |
| Length | 18.41mm |
| Lifecycle Status | Production |
| Max Operating Temperature | 85°C |
| Max Supply Current | 35mA |
| Max Supply Voltage | 3.6V |
| Memory Size | 256kB |
| Memory Type | RAM, SDR, SRAM - Asynchronous |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 2.4V |
| Nominal Supply Current | 35mA |
| Number of Circuits | 1 |
| Number of Pins | 44 |
| Number of Ports | 1 |
| Number of Terminals | 44 |
| Number of Words | 256000 |
| Operating Supply Voltage | 3V |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Sync/Async | Asynchronous |
| Temperature Grade | Industrial |
| Terminal Pitch | 800µm |
| Width | 10.16mm |
| Word Size | 8b |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
