IS62WV10248DBLL-55TLI - ISSI
SRAM, 8MBIT, 55NS, 44TSOPII; Memory Size: 8Mbit; Memory Configuration: 1M x 8; Sup
Technical Details
| Access Time | 55ns |
| Address Bus Width | 20b |
| Case/Package | TSOP |
| China RoHS | Compliant |
| Country of Origin | Mainland China, Taiwan |
| Density | 8Mb |
| Export Control Classification Number (ECCN) Code | 3A991.b.2.a |
| Height - Seated (Max) | 1.2mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.32.00.41 |
| Interface | Parallel |
| Introduction Date | 2008-09-18 |
| Length | 18.415mm |
| Lifecycle Status | Production |
| Max Operating Temperature | 70°C |
| Max Supply Current | 22mA |
| Max Supply Voltage | 2.2V |
| Memory Size | 1MB |
| Memory Type | RAM, SRAM - Asynchronous |
| Min Operating Temperature | 0°C |
| Min Supply Voltage | 1.65V |
| Nominal Supply Current | 25mA |
| Number of Circuits | 1 |
| Number of Pins | 44 |
| Number of Ports | 1 |
| Number of Terminals | 44 |
| Operating Supply Voltage | 1.8V |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Schedule B | 8542320040 |
| Sync/Async | Asynchronous |
| Temperature Grade | Commercial |
| Terminal Pitch | 800µm |
| Width | 10.16mm |
| Word Size | 8b |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
