Technical Details
| Color | Grey |
| Connector Type | Receptacle, Rectangular, Socket |
| Contact Gender | Female |
| Contact Material | Copper |
| Contact Plating | Tin |
| Current Rating | 3A |
| Depth | 21.3mm |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Gender | Female |
| Height | 12.2mm |
| Housing Material | PPE |
| Harmonized Tariff Schedule (HTS) Code | 8536.69.40.30 |
| Introduction Date | 2008-12-25 |
| Lifecycle Status | Production |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Cable, Free Hanging |
| Number of Contacts | 3 |
| Number of Pins | 3 |
| Number of Positions | 3 |
| Number of Rows | 1 |
| Packaging | Bulk |
| Pitch | 2.2098mm |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Termination | Crimp |
| Width | 10.8mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
