T491A225M035AT - KEMET
Cap Tant Solid 2.2uF 35V A CASE 20% (3.2 X 1.6 X 1.6mm) Inward L SMD 3216-18 4 Ohm 125C T/R
Technical Details
| Capacitance | 2.2µF |
| Case/Package | 1206 |
| Case Code (Imperial) | 1206 |
| Case Code (Metric) | 3216 |
| China RoHS | Compliant |
| Country of Origin | Mexico |
| Depth | 1.6mm |
| Dissipation Factor | 6% |
| Export Control Classification Number (ECCN) Code | EAR99 |
| ESR (Equivalent Series Resistance) | 4Ω |
| Features | General Purpose |
| Height | 1.6mm |
| Height - Seated (Max) | 1.8034mm |
| Harmonized Tariff Schedule (HTS) Code | 8532.21.00.50 |
| Introduction Date | 2010-10-28 |
| Lead Free | Lead Free |
| Leakage Current | 800nA |
| Length | 3.2mm |
| Life (Hours) | 2000hours |
| Lifecycle Status | Production |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Terminals | 2 |
| Packaging | Tape & Reel |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Ripple Current | 52mA |
| RoHS | Compliant |
| Schedule B | 8532210050, 8532210050|8532210050|8532210050|8532210050|8532210050 |
| Tolerance | 20% |
| Voltage Rating | 35V |
| Voltage Rating (DC) | 35V |
| Width | 1.6mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
