T520B227M006ATE045 - KEMET
Cap Tant Solid 220uF 6.3V B CASE 20% (3.5 X 2.8 X 1.9mm) SMD 3528-21 0.045 Ohm 105 C T/R
Technical Details
| Capacitance | 220µF |
| Case/Package | 1411 |
| Case Code (Imperial) | 1411 |
| Case Code (Metric) | 3528 |
| China RoHS | Compliant |
| Depth | 2.8mm |
| Dissipation Factor | 8% |
| Export Control Classification Number (ECCN) Code | EAR99 |
| ESR (Equivalent Series Resistance) | 45mΩ |
| Features | General Purpose |
| Height | 1.9mm |
| Height - Seated (Max) | 2.1082mm |
| Harmonized Tariff Schedule (HTS) Code | 8532.21.00.50 |
| Introduction Date | 2010-10-05 |
| Leakage Current | 138.6µA |
| Length | 3.5mm |
| Life (Hours) | 2000hours |
| Lifecycle Status | Production |
| Max Operating Temperature | 105°C |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Packaging | Cut Tape |
| Polarity | Polar |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Ripple Current | 425mA |
| RoHS | Compliant |
| Schedule B | 8532210050, 8532210050|8532210050, 8532210050|8532210050|8532210050, 8532210050|8532210050|8532210050|8532210050 |
| Termination | SMD/SMT |
| Tolerance | 20% |
| Voltage Rating | 6.3V |
| Voltage Rating (DC) | 6.3V |
| Width | 2.8mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
