AAA3528LSEKJ3ZGKQBKS - Kingbright
Triple Color LED, Hyper Red/green/blue, Water Clear, 2.4mm
Technical Details
| Case/Package | PLCC |
| China RoHS | Compliant |
| Color | Blue, Green, Red |
| Country of Origin | Mainland China |
| Dominant Wavelength | 465nm |
| Forward Current | 30mA |
| Forward Voltage | 2.1V |
| Height | 1.8mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.40.20.00 |
| Introduction Date | 2018-09-05 |
| Length | 3.2mm |
| Lens Color | Colorless |
| Lens Transparency | Clear |
| Lifecycle Status | Production |
| Luminous Intensity | 30mcd |
| Max Junction Temperature (Tj) | 115°C |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Circuits | 1 |
| Number of Terminals | 4 |
| REACH SVHC | Yes |
| Reverse Voltage | 5V |
| RoHS | Compliant |
| Shape | Round |
| Terminal Pitch | 1.45mm |
| Test Current | 2mA |
| Viewing Angle | 120° |
| Wavelength | 625nm |
| Width | 2.8mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
