APG1608CGKC/T - Kingbright
APG1608CGKC/T Green LED; 570 nm 1608 (0603) Clear; Rectangle Lens SMD package
Technical Details
| Case/Package | 0603 |
| Case Code (Imperial) | 0603 |
| Case Code (Metric) | 1608 |
| China RoHS | Compliant |
| Color | Green |
| Country of Origin | Mainland China |
| Dominant Wavelength | 570nm |
| Forward Current | 30mA |
| Forward Voltage | 2.6V |
| Height | 250µm |
| Harmonized Tariff Schedule (HTS) Code | 8541.40.20.00 |
| Illumination Color | Green |
| Introduction Date | 2009-03-31 |
| Lead Free | Lead Free |
| Length | 1.6mm |
| Lens Color | Clear, Colorless |
| Lens Style | Clear |
| Lens Transparency | Clear |
| Lifecycle Status | Production |
| Luminous Intensity | 60mcd |
| Max Junction Temperature (Tj) | 115°C |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Circuits | 1 |
| Number of LEDs | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Packaging | Cut Tape (CT) |
| Peak Wavelength | 574nm |
| Power Dissipation | 78mW |
| Power Rating | 78mW |
| REACH SVHC | Yes |
| Reverse Voltage | 5V |
| RoHS | Compliant |
| Schedule B | 8541402000, 8541402000|8541402000, 8541402000|8541402000|8541402000, 8541402000|8541402000|8541402000|8541402000 |
| Shape | Rectangular |
| Terminal Pitch | 1.65mm |
| Test Current | 20mA |
| Viewing Angle | 120° |
| Wavelength | 570nm |
| Width | 800µm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
