Technical Details
| Case/Package | 0805 |
| Case Code (Imperial) | 0805 |
| Case Code (Metric) | 2012 |
| China RoHS | Compliant |
| Color | Green |
| Dominant Wavelength | 570nm |
| Forward Current | 30mA |
| Forward Voltage | 2.5V |
| Height | 750µm |
| Harmonized Tariff Schedule (HTS) Code | 8541.40.20.00 |
| Illumination Color | Green |
| Introduction Date | 2000-12-14 |
| Lead Free | Lead Free |
| Length | 2mm |
| Lens Color | Colorless |
| Lens Style | Clear |
| Lens Transparency | Clear |
| Lifecycle Status | Production |
| Luminous Intensity | 70mcd |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Circuits | 1 |
| Number of Terminals | 2 |
| Peak Wavelength | 574nm |
| Power Dissipation | 75mW |
| Power Rating | 75mW |
| REACH SVHC | Yes |
| Reverse Voltage | 5V |
| RoHS | Compliant |
| Shape | Rectangular |
| Terminal Pitch | 2.35mm |
| Test Current | 20mA |
| Viewing Angle | 120° |
| Wavelength | 570nm |
| Width | 1.25mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
Images
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Lumex | Production | ||
| Kingbright | Production | ||
| Kingbright | Production | ||
| Lumex | Production | ||
| Kingbright | Production | ||
| Lumex | Production | ||
| Kingbright | Production | ||
| Lumex | Production | ||
| Kingbright | Production | ||
| Lite-On | Production |
