APTF1616SEEZGQBDC - Kingbright
LED Low-Power Tri-Color Blue/Green/Hyper Red 460nm/515nm/630nm 3.3V/3.3V/2V 4-Pin SMD T/R
Technical Details
| Case/Package | 0606 |
| Case Code (Imperial) | 0606 |
| Case Code (Metric) | 1616 |
| China RoHS | Compliant |
| Color | Blue, Green, Red |
| Country of Origin | Mainland China |
| Dominant Wavelength | 465nm |
| Forward Current | 30mA |
| Forward Voltage | 2.5V |
| Height | 700µm |
| Harmonized Tariff Schedule (HTS) Code | 8541.40.20.00 |
| Introduction Date | 2010-10-29 |
| Lead Free | Lead Free |
| Length | 1.6mm |
| Lens Color | Colorless |
| Lens Style | Clear |
| Lens Transparency | Clear |
| Lifecycle Status | Production |
| Luminous Intensity | 110mcd |
| Max Junction Temperature (Tj) | 115°C |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Circuits | 1 |
| Number of Terminals | 4 |
| Power Rating | 120mW |
| REACH SVHC | Yes |
| Reverse Voltage | 5V |
| RoHS | Compliant |
| Schedule B | 8541402000, 8541402000|8541402000, 8541402000|8541402000|8541402000, 8541402000|8541402000|8541402000|8541402000 |
| Shape | Rectangular |
| Terminal Pitch | 850µm |
| Test Current | 20mA |
| Viewing Angle | 120° |
| Wavelength | 621nm |
| Width | 1.6mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
