Technical Details
| Case/Package | DIP |
| Character Width | 14.224mm |
| Color | Red |
| Depth | 12.6mm |
| Dominant Wavelength | 623nm |
| Element Configuration | Common Anode |
| Forward Current | 25mA |
| Forward Voltage | 2.8V |
| Height | 19.05mm |
| Illumination Color | Red |
| Lead Free | Lead Free |
| Length | 19.05mm |
| Lifecycle Status | Production |
| Luminous Intensity | 2.4mcd |
| Max Operating Temperature | 85°C |
| Max Power Dissipation | 75mW |
| Min Operating Temperature | -35°C |
| Mount | Through Hole |
| Number of Characters | 1 |
| Number of Circuits | 1 |
| Number of Elements | 8 |
| Number of Pins | 10 |
| Operating Supply Voltage | 2.6V |
| Peak Wavelength | 635nm |
| Power Dissipation | 75mW |
| Radiation Hardening | No |
| REACH SVHC | No |
| Reverse Voltage | 5V |
| RoHS | Compliant |
| Schedule B | 8531200040, 8531200040|8531200040|8531200040|8531200040|8531200040 |
| Test Current | 10mA |
| Viewing Area (height) | 14.22mm |
| Wavelength | 635nm |
| Width | 12.5984mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
