LTST-C193TBKT-5A - Lite-On
LED blue 0603 wavelength 465~475nm light intensity 15mcd Front Mounting
Technical Details
| Case/Package | 0603 |
| Case Code (Imperial) | 0603 |
| Case Code (Metric) | 1608 |
| China RoHS | Compliant |
| Color | Blue |
| Contact Plating | Tin |
| Depth | 800µm |
| Dominant Wavelength | 475nm |
| Forward Current | 20mA |
| Forward Voltage | 2.8V |
| Height | 350µm |
| Illumination Color | Blue |
| Lead Free | Lead Free |
| Length | 1.6mm |
| Lens Color | Clear, Colorless |
| Lens Style | Clear, Colorless, Diffused, Rectangular |
| Lens Transparency | Clear |
| Lifecycle Status | Production |
| Luminous Intensity | 15mcd |
| Max Operating Temperature | 80°C |
| Min Operating Temperature | -20°C |
| Mount | Surface Mount |
| Number of Circuits | 1 |
| Number of Elements | 1 |
| Number of LEDs | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Peak Wavelength | 468nm |
| Power Dissipation | 76mW |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Reverse Voltage | 5V |
| RoHS | Compliant |
| Schedule B | 8541402000, 8541402000|8541402000|8541402000|8541402000|8541402000 |
| Shape | Rectangular |
| Terminal Pitch | 1.5mm |
| Test Current | 5mA |
| Viewing Angle | 130° |
| Wavelength | 470nm |
| Width | 800µm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
