Technical Details
| Case/Package | 1208 |
| Color | Blue |
| Contact Plating | Tin |
| Depth | 2mm |
| Dominant Wavelength | 470nm |
| Forward Current | 20mA |
| Forward Voltage | 3.4V |
| Height | 1mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.40.20.00 |
| Illumination Color | Blue |
| Introduction Date | 2001-06-05 |
| Lead Free | Lead Free |
| Length | 3mm |
| Lens Color | Colorless |
| Lens Transparency | Clear |
| Lifecycle Status | Production |
| Luminous Intensity | 104mcd |
| Max Operating Temperature | 80°C |
| Min Operating Temperature | -20°C |
| Mount | Surface Mount |
| Number of Circuits | 1 |
| Number of Elements | 1 |
| Number of Terminals | 3 |
| Peak Wavelength | 468nm |
| Power Dissipation | 76mW |
| REACH SVHC | Yes |
| Reverse Voltage | 5V |
| RoHS | Compliant |
| Shape | Rectangular |
| Terminal Pitch | 3.5mm |
| Test Current | 20mA |
| Viewing Angle | 130° |
| Wavelength | 468nm |
| Width | 2mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
