1812L035/30DR - Littelfuse
PTC Resettable Fuse 0.35A(hold) 0.75A(trip) 30VDC 40A 0.8W 0.15s 0.4Ohm SMD Solder Pad 1812 T/R
Technical Details
| Ambient Temperature Range High | 85°C |
| Approvals | TUV, cULus |
| Case/Package | 1812 |
| Case Code (Imperial) | 1812 |
| Case Code (Metric) | 4532 |
| Current Rating | 40A |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 1.25mm |
| Hold Current | 350mA |
| Harmonized Tariff Schedule (HTS) Code | 8533.40.80.70 |
| Introduction Date | 2012-03-02 |
| Lead Free | Lead Free |
| Length | 4.73mm |
| Lifecycle Status | Production |
| Max Current Rating | 40A |
| Max Operating Temperature | 85°C |
| Maximum Resistance 1 Hour (R1max) | 1.7Ω |
| Max Voltage Rating (DC) | 30V |
| Min Operating Temperature | -40°C |
| Minimum Resistance Initial (Rmin) | 400mΩ |
| Mount | Surface Mount |
| Number of Terminals | 2 |
| Power Dissipation | 800mW |
| REACH SVHC | Yes |
| Resistance | 400mΩ |
| RoHS | Compliant |
| Termination | SMD/SMT |
| Time to Trip | 150ms |
| Trip Current | 750mA |
| Voltage Rating | 30V |
| Voltage Rating (DC) | 30V |
| Width | 3.41mm |
| Working Voltage | 30V |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
