2016L030DR - Littelfuse
PTC Resettable Fuse 0.3A(hold) 0.6A(trip) 60VDC 20A 1.4W 3s 0.5Ohm SMD Solder Pad 2016 T/R
Technical Details
| Ambient Temperature Range High | 85°C |
| Approvals | TUV, cULus |
| Case/Package | 2016 |
| Case Code (Imperial) | 2016 |
| Case Code (Metric) | 5041 |
| Current Rating | 20A |
| Height | 1.25mm |
| Hold Current | 300mA |
| Lead Free | Lead Free |
| Length | 5.44mm |
| Lifecycle Status | Production |
| Max Current Rating | 20A |
| Max Operating Temperature | 85°C |
| Maximum Resistance 1 Hour (R1max) | 2.3Ω |
| Max Voltage Rating (DC) | 60V |
| Min Operating Temperature | -40°C |
| Minimum Resistance Initial (Rmin) | 500mΩ |
| Mount | Surface Mount |
| Number of Terminals | 2 |
| Operating Supply Voltage | 60V |
| Packaging | Cut Tape |
| Power Dissipation | 1.4W |
| REACH SVHC | Yes |
| Resistance | 500mΩ |
| RoHS | Compliant |
| Terminal Material | Copper |
| Termination | SMD/SMT |
| Time to Trip | 3s |
| Trip Current | 600mA |
| Voltage Rating | 60V |
| Voltage Rating (DC) | 60V |
| Width | 4.43mm |
| Working Voltage | 60V |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
