2920L500/16MR - Littelfuse
PTC Resettable Fuse 5A(hold) 10A(trip) 16VDC 40A 2W 5s 0.005Ohm SMD Solder Pad 2920 T/R Automotive
Technical Details
| Ambient Temperature Range High | 85°C |
| Case/Package | 2920 |
| Case Code (Imperial) | 2920 |
| Case Code (Metric) | 7351 |
| China RoHS | Compliant |
| Current Rating | 40A |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 1.6mm |
| Hold Current | 5A |
| Harmonized Tariff Schedule (HTS) Code | 8533.40.80.70 |
| Introduction Date | 2013-11-12 |
| Lead Free | Lead Free |
| Length | 7.98mm |
| Lifecycle Status | Production |
| Max Current Rating | 40A |
| Max Operating Temperature | 85°C |
| Max Power Dissipation | 2W |
| Maximum Resistance 1 Hour (R1max) | 25mΩ |
| Min Operating Temperature | -40°C |
| Minimum Resistance Initial (Rmin) | 5mΩ |
| Mount | Surface Mount |
| Number of Terminals | 2 |
| Power Dissipation | 2W |
| REACH SVHC | Yes |
| Resistance | 5mΩ |
| RoHS | Compliant |
| Termination | SMD/SMT |
| Time to Trip | 5s |
| Trip Current | 10A |
| Voltage Rating | 16V |
| Voltage Rating (DC) | 16V |
| Width | 5.44mm |
| Working Voltage | 16V |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
