P6KE180A - Littelfuse
P6KE Series 171 V 600 W Through Hole Uni-Directional TVS Diode - DO-204AC
Technical Details
| Breakdown Voltage | 180V |
| Case/Package | DO-15 |
| China RoHS | Non-Compliant |
| Clamping Voltage | 246V |
| Composition | Zener |
| Diameter | 3.6mm |
| Direction | Unidirectional |
| Lead Free | Lead Free |
| Leakage Current | 1µA |
| Length | 7.6mm |
| Lifecycle Status | Production |
| Max Breakdown Voltage | 189V |
| Max Operating Temperature | 175°C |
| Max Power Dissipation | 5W |
| Max Reverse Leakage Current | 1µA |
| Max Surge Current | 2.4A |
| Min Breakdown Voltage | 171V |
| Min Operating Temperature | -55°C |
| Mount | Through Hole |
| Number of Channels | 1 |
| Number of Elements | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Number of Unidirectional Channels | 1 |
| Operating Supply Voltage | 154V |
| Peak Pulse Current | 2.5A |
| Peak Pulse Power | 600W |
| Polarity | Unidirectional |
| Power Dissipation | 600W |
| Power Line Protection | No |
| REACH SVHC | No |
| Reverse Breakdown Voltage | 171V |
| Reverse Standoff Voltage | 154V |
| Reverse Voltage | 154V |
| RoHS | Compliant |
| Termination | Axial |
| Test Current | 1mA |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
Images
RS
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| onsemi | Obsolete | ||
| Multicomp | Unknown | ||
| Taiwan Semiconductor | Production | ||
| onsemi | Obsolete | ||
| Taiwan Semiconductor | Production | ||
| Littelfuse | Production | ||
| Diodes Inc. | Obsolete | ||
| STMicroelectronics | Obsolete | ||
| Rectron | Production | ||
| Vishay | Obsolete |
