RXEF005-2 - Littelfuse
PTC Resettable Fuse 0.05A(hold) 0.1A(trip) 60V 40A 0.26W 5s 7.3Ohm Radial 8 X 3 X 8.3mm T/R
Technical Details
| Ambient Temperature Range High | 85°C |
| Case/Package | Radial |
| China RoHS | Compliant |
| Current Rating | 40A |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 8.3mm |
| Hold Current | 50mA |
| Harmonized Tariff Schedule (HTS) Code | 8533.40.80.70 |
| Introduction Date | 2008-12-19 |
| Length | 8mm |
| Lifecycle Status | Production |
| Max Current Rating | 40A |
| Max Operating Temperature | 85°C |
| Maximum Resistance 1 Hour (R1max) | 20Ω |
| Min Operating Temperature | -40°C |
| Minimum Resistance Initial (Rmin) | 7.3Ω |
| Number of Terminals | 2 |
| Packaging | Tape & Reel |
| Power Dissipation | 220mW |
| REACH SVHC | Yes |
| Resistance | 7.3Ω |
| RoHS | Compliant |
| Schedule B | 8536100040|8536100040 |
| Time to Trip | 5s |
| Trip Current | 100mA |
| Voltage Rating | 60V |
| Width | 3mm |
| Working Voltage | 60V |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
