RXEF375K - Littelfuse
PTC Resettable Fuse 3.75A(hold) 7.5A(trip) 72VAC/72VDC 40A 3.2W 24s 0.03Ohm Radial 27.2 X 3mm Bag
Technical Details
| Ambient Temperature Range High | 85°C |
| Case/Package | Radial |
| China RoHS | Compliant |
| Current Rating | 40A |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 31.1mm |
| Hold Current | 3.75A |
| Harmonized Tariff Schedule (HTS) Code | 8533.40.80.70 |
| Introduction Date | 2014-01-20 |
| Length | 26.3mm |
| Lifecycle Status | Production |
| Max Current Rating | 40A |
| Max Operating Temperature | 85°C |
| Maximum Resistance 1 Hour (R1max) | 80mΩ |
| Min Operating Temperature | -40°C |
| Minimum Resistance Initial (Rmin) | 30mΩ |
| Number of Terminals | 2 |
| Packaging | Bulk |
| Power Dissipation | 3.2W |
| REACH SVHC | Yes |
| Resistance | 30mΩ |
| RoHS | Compliant |
| Schedule B | 8536100040, 8536100040|8536100040|8536100040|8536100040|8536100040 |
| Time to Trip | 24s |
| Trip Current | 7.5A |
| Voltage Rating | 72V |
| Width | 3mm |
| Working Voltage | 72V |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
