SP0504BAHTG - Littelfuse
SP050xBA Series 8 V 30 pF Uni-Directional SMT TVS Avalanche Diode Array SOT-23-5
Technical Details
| Breakdown Voltage | 5.5V |
| Capacitance | 30pF |
| Case/Package | SOT-23 |
| Clamping Voltage | 6.8V |
| Composition | Zener |
| Country of Origin | Mainland China |
| Depth | 1.75mm |
| Diode Type | Avalanche |
| Direction | Unidirectional |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Common Anode |
| ESD Protection | Yes |
| Height | 1.45mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 2002-07-25 |
| Lead Free | Lead Free |
| Leakage Current | 100nA |
| Length | 3.05mm |
| Lifecycle Status | Production |
| Max Operating Temperature | 125°C |
| Max Power Dissipation | 225mW |
| Max Reverse Leakage Current | 100nA |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Channels | 4 |
| Number of Elements | 4 |
| Number of Pins | 5 |
| Number of Terminals | 5 |
| Number of Unidirectional Channels | 4 |
| Operating Supply Voltage | 5.5V |
| Packaging | Cut Tape |
| Peak Pulse Power | 25W |
| Polarity | Unidirectional |
| Power Dissipation | 225mW |
| Power Line Protection | No |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Reverse Standoff Voltage | 5.5V |
| RoHS | Compliant |
| Schedule B | 8536300000, 8536300000|8536300000, 8536300000|8536300000|8536300000, 8536300000|8536300000|8536300000|8536300000 |
| Termination | SMD/SMT |
| Voltage Rating (DC) | 5V |
| Width | 1.75mm |
| Working Voltage | 5.5V |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
