24AA64T-I/SM - Microchip
I²C™ Serial EEPROM, 1.7 to 5.5V, 400 kHz, -40 to 125°C, SOIJ-8, RoHS
Technical Details
| Projected EOL Date | 2034-01-01 |
| Access Time | 900ns |
| Case/Package | SOIC |
| Contact Plating | Tin |
| Country of Assembly | Thailand |
| Country of Fabrication | Taiwan, United States of America |
| Country of Origin | Thailand |
| Density | 64kb |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Frequency | 400kHz |
| Harmonized Tariff Schedule (HTS) Code | 8542.32.0051 |
| Interface | I2C, Serial |
| Introduction Date | 2002-01-01 |
| Lead Free | Lead Free |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | REL |
| Max Frequency | 400kHz |
| Max Operating Temperature | 85°C |
| Max Supply Voltage | 5.5V |
| Memory Type | EEPROM |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 1.7V |
| Mount | Surface Mount |
| Nominal Supply Current | 3mA |
| Number of Pins | 8 |
| Packaging | Tape & Reel (TR) |
| Radiation Hardening | No |
| RoHS | Compliant |
| Schedule B | 8542320050 |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
Images
Microchip
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Microchip | Unknown | ||
| Microchip | Production | ||
| Microchip | Unknown | ||
| Microchip | Production | ||
| Microchip | Production | ||
| onsemi | Production | ||
| Microchip | Production | ||
| Siemens | Obsolete | ||
| Microchip | Production | ||
| STMicroelectronics | Obsolete |
